Camera

• Sensor: 1/2.5"Sony Exmor 4K CMOS sensor
• Frame rate: 4K 30fps; 1080p , 720p , 960x540, 848x480, 800x448, 640x480, 640x360, 424x240, 320x240, 320x180 at up to 60fps
• 120° Wide field of view
• Lens iris, focus, zoom: fixed
• AE, white balance: auto, manual override by PTZApp
• Minimum working distance: 80cm
• Back light compensation and 2D noise reduction technology for optimizing light balance in different conditions
• Standard tripod screw holes

Zoom, Pan, and Tilt Movement

• Zoom: up to 4X leveraging 4K sensor (not available in 4K or 60fps)
• Pan and tilt: when zoomed in leveraging 4K sensor

Microphone

• 1 uni-directional microphones
• Frequency response: 100~12K Hz
• Sensitivity: -37dB

Connectivity

• USB Type C connector
• Reset button
• DC jack for power adapter (for USB 2.0 connection)

Video Format

• YUV, MJPEG

USB

• 2.0, 3.1 Gen1 type C
• UVC (USB Video Class) 1.1

Control

• IR remote control (optional accessory, compatible with CAM540)
• UVC / plug-and play
• PTZApp

Security and Mount

• Built-in TV mount (above TV, up to 46 mm deep)
• Kensington slot
• 1/4" tripod mounting screw

System Requirement

• Windows 7/10/11
• MacOS 10.14 or higher
• Chromebox 3 version 94.0.4606.114 or later

Hardware Spec

• 2.4GHz Intel@ Core 2 Duo processor
• 2GB RAM or more
• USB 2.0 port and above (USB 3.1 required for 4K or 60fps)

Power Supply

• Consumption: USB 3.1 Supports up to 4K : 5V/0.9A;
• USB 2.0 Supports up to 2K: 5V/0.5A

Environmental Data

• Operation temperature: 0 ~40°C
• Operation humidity: 20% ~80%
• Storage temperature: -20 ~60°C
• Storage humidity: 20% ~80%

Dimension

• Package dimensions: 138 x 138 x 149 mm
• Package weight: 0.622 kg
• Camera (folded): 60 x 60 x 75 mm
• Camera weight: 0.251 kg

Package Contents

• USB3.0 4K Camera
• USB3.1 type-C to type-A Cable (6ft)
• Quick-start guide

Optional Accessories

• Wall mount
• Remote control (compatible with CAM540)
• Power adapter (for USB 2.0)

Compatible Applications

• ZOOM, Microsoft® Teams, Skype for Business, Skype™, Google Hangouts, Intel® Unite™, RingCentral, BlueJeans, V-Cube, LiveOn, CyberLink U Meeting®, TrueConf, Adobe Connect, Cisco WebEx®, Fuze, GoToMeeting™, Microsoft® Lync™, Vidyo, vMix, WebRTC, Wirecast, XSplit
