• Double Panorama Mode When the camera is installed on the ceiling, the entire area under the camera is displayed as two 180° panoramic images. • Panorama Mode When the camera is installed on a wall, the 180° area in front of the camera is displayed as a panoramic image. Blind spots that occur at the left and right sides of the image when using a 104° horizontal wide-angle camera (WV-SW155) are captured clearly. • Quad PTZ Mode 4 VGA size (640 x 480 dot) images displayed on one screen. Images in all four directions from the camera installation location are displayed on one screen. You can click on areas within images that you want to see, display a 360° fisheye image at the side of the display, and move to positions that you want to see simply by clicking. • Single PTZ Mode Displays one quad VGA size (1280 x 960 dot) image. You change the display area by clicking the area you want to see in the image. • Fisheye Mode Displays full 360° fisheye images, enabling monitoring without blind spots. Shooting in all directions means that the path of everyone walking beneath the camera can be monitored. Images can be displayed in 3Mbps or 1.3 Mbps modes.
Indoor / Outdoor |
Indoor |
|
---|---|---|
Image sensor |
1/3 MOS |
|
Min. Illumination Color (lx) |
1.5 |
|
Min. Illumination B/W (lx) |
1.2 |
|
Maximum Resolution |
2MP – 3MP (1,080p / 2,048 x 1,536) |
|
Maximum FPS |
30 |
|
Super Dynamic |
Yes |
|
Image compensation |
Adaptive Black Stretch, Digital noise reduction |
|
Color/BW |
Electrical |
|
ABF(Auto back focus)/Auto Focus/Focus Assist |
- |
|
IR LED |
- |
|
Image Stabilizer |
- |
|
Corridor Mode |
- |
|
Privacy Zone |
4 |
|
iA (Intelligent Auto) |
- |
|
Intelligent VMD (i-VMD) |
Type1 |
|
Focal length |
f=0.837mm, F2.4 |
|
Zoom ratio |
- |
|
Angular field of view (16:9) |
H: 182 deg. V: 176 deg. (1:1) |
|
Panning Range |
- |
|
Tilting Range |
- |
|
Network IF |
10Base-T, 100Base-TX, RJ45 connector |
|
Video Codec |
H.264, JPEG |
|
Transmission mode (H.265/H.264) |
Constant bit rate, Advanced variable bit rate, Frame rate, Best effort |
|
Smart Coding |
- |
|
Audio Support |
Yes |
|
Built-in microphone |
- |
|
Microphone/Line Input |
Yes |
|
Audio Output |
Yes |
|
SD memory Card Slot |
SDXC |
|
External I/O Terminals |
Yes |
|
Ambient Operating Humidity |
Less than 90 |
|
Vandal Resistant |
IK10 (IEC62262) |
|
Water and Dust Resistance |
IP66 (IEC60529), Type 4X(UL50), NEMA 4X |
|
ClearSight Coating / Rain Wash Coating |
- |
|
Dehumidification device |
Yes |
|
Temperature (degree, Celsius) |
MAX |
50 |
MIN |
-40 |
|
Temperature (degree, Fahrenheit) |
MAX |
122 |
MIN |
-40 |
|
Power Source |
PoE, 12V DC |
|
SSL device certificate |
- |
|
ONVIF Profile |
S |
• 4 Stream Mode
Four VGA size (640 x 480 dot) images are transmitted. The operator sets the orientation beforehand
